Buick Envista I (2022-2024) eng ctrl sens 5 volt ref 1 Wiring diagram
This page shows the only wiring diagram for the component.eng ctrl sens 5 volt ref 1, which is found in the car Buick Envista I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram eng ctrl sens 5 volt ref 1 (1 of 1)
AMBIENT AIR TEMP SENS SIG
AMBIENT AIR TEMPERATURE SENSOR
BATT POS VOLT
BLK/BLU WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRY WIRE
BLU/RED WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR LATCH ASSEMBLY
DRIVER WINDOW SWITCH
ENG CTRL SENS 5 VOLT REF 1
ENGINE CONTROL MODULE (RIGHT SIDE OF ENGINE COMPT)
ENGINE CTRL SENS LO REF 2
ENGINE OIL PRESSURE SENSOR
GRN/GRY WIRE
GRN/YEL WIRE
GRY WIRE
HI SPD GMLAN SER DATA (+) 1
LEFT REAR DOOR LATCH ASSEMBLY
LEFT REAR WINDOW SWITCH
LOGIC
OIL PRESSURE SENS SIG
PASSENGER DOOR LATCH ASSEMBLY
PASSENGER WINDOW SWITCH
RED/WHT WIRE
RIGHT REAR DOOR LATCH ASSEMBLY
RIGHT REAR WINDOW SWITCH
SIG GND
WHT WIRE
YEL/BRN WIRE
Go to component: -> Instrument cluster circuit (3 of 3) -> ENG CTRL SENS 5 VOLT REF 1
