Buick Envista I (2022-2024) defrost, lower air outlet ind Wiring diagram
This page shows the only wiring diagram for the component.defrost, lower air outlet ind, which is found in the car Buick Envista I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram defrost, lower air outlet ind (1 of 1)
A/C COMPRESSOR CLUTCH RELAY
A/C IND
A/C SWITCH
AUTO IND
AUTO SWITCH
BLK/WHT WIRE
BLU/GRY WIRE
BRN/GRN WIRE
BRN/YEL WIRE
COOLING FAN HIGH SPEED RELAY
COOLING FAN LOW SPEED RELAY
COOLING FAN MEDIUM SPEED RELAY
DEFROST, LOWER AIR OUTLET IND
DEFROST, LOWER AIR OUTLET SWITCH
ENGINE CONTROLS IGNITION RELAY
FAN DOWN SWITCH
FAN UP SWITCH
GRN WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY WIRE
HVAC CONTROLS
LEFT TEMPERATURE DOWN SWITCH
LEFT TEMPERATURE UP SWITCH START/ STOP SWITCH RIGHT TEMPERATURE DOWN SWITCH
LOGIC
LOWER AIR OUTLET IND
LOWER AIR OUTLET SWITCH
RECIRCULATION IND
RECIRCULATION SWITCH
RED/BLU WIRE
RED/BRN WIRE
RED/WHT WIRE
RIGHT TEMPERATURE UP SWITCH
START STOP IND
TEMPERATURE CONTROL
UNDERHOOD FUSE BLOCK
UPPER AIR OUTLET IND
UPPER AIR OUTLET SWITCH
UPPER, LOWER AIR OUTLET IND
UPPER, LOWER AIR OUTLET SWITCH
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRY WIRE
WINDSHIELD DEFROST IND
WINDSHIELD DEFROST SWITCH
YEL WIRE
Go to component: -> Automatic a/c circuit (3 of 5) -> DEFROST, LOWER AIR OUTLET IND
