Buick Envista I (2022-2024) cluster control module Wiring diagram
This page shows the only wiring diagram for the component.cluster control module, which is found in the car Buick Envista I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cluster control module (1 of 1)
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CLUSTER CONTROL MODULE
ETHERNET BUS 4 (-)
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRY WIRE
GRY/GRN WIRE
GRY/WHT WIRE
HI SPD GMLAN
INFOTAINMENT DISPLAY SIG
INSTRUMENT CLUSTER
INSTRUMENT PANEL
LEFT SIDE OBJECT SENSOR MODULE
LIN BUS 1
LIN BUS 2
LO SPD GMLAN
LOGIC
LOW SPEED GMLAN
LVDS
RADIO
RADIO CONTROLS
RIGHT SIDE OBJECT SENSOR MODULE
RIGHT STEERING WHEEL CONTROLS SWITCH
SEAT HEATING CONTROL MODULE
SERIAL DATA
SERIAL DATA (-) 5
SERIAL DATA 2
STEERING WHEEL AIR BAG COIL
TRANSMISSION SHIFT LEVER POSITION INDICATOR
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/GRY WIRE
Go to component: -> Computer data lines circuit (2 of 7) -> CLUSTER CONTROL MODULE
