Buick Envista I (2022-2024) accessory wakeup Wiring diagrams

A/C IND ACCESSORY WAKEUP AMBIENT LIGHT SENS SIG AMBIENT LIGHT/SUNLOAD SENSOR (TOP CENTER OF DASH) BATT POS VOLT BATTERY FUSE BLOCK BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLU/GRY WIRE BLU/WHT WIRE BODY CONTROL MODULE (BELOW CENTER OF DASH) COMMUNICATION ENABLE COMPUTER DATA LINES SYSTEM COOLING FAN MOTOR (BEHIND RADIATOR) DISPLAY SIG + DRIVER INFORMATION CENTER DISPLAY ENGINE COOLANT TEMPERATURE GAUGE ENGINE COOLANT TEMPERATURE IND ETHERNET BUS 4 (-) GRN WIRE GRN/YEL WIRE GRY WIRE GRY/WHT WIRE HOT AT ALL TIMES INFOTAINMENT INSTRUMENT CLUSTER INSTRUMENT PANEL FUSE BLOCK LOGIC LVDS RADIO RED/BLU WIRE RED/BRN WIRE RED/WHT WIRE SECURITY IND CTRL SERIAL DATA SIG GND UNDERHOOD FUSE BLOCK VIO/YEL WIRE WHT/BLU WIRE YEL WIRE

ACCESSORY IGN VOLT ACCESSORY WAKEUP BLU WIRE BLU/GRY WIRE BLU/YEL WIRE BODY CONTROL MODULE BODY CONTROL MODULE (BELOW CENTER OF DASH) COMMUNICATION ENABLE CONTROL SOLENOID VALVE ASSEMBLY GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/VIO WIRE GRN/YEL WIRE HI SPD GMLAN HIGH SPEED BUS TERMINATING RESISTOR IMMO LIN BUS 1 IMMOBILIZER CONTROL MODULE LEFT REAR WINDOW SWITCH LIN BUS 1 LIN BUS 2 LIN BUS 3 LIN BUS 4 LO SPD GMLAN RAIN/AMBIENT LIGHT SENSOR MODULE RIGHT REAR WINDOW SWITCH SERIAL DATA SERIAL DATA (-) (1) SUNROOF MOTOR VIO/YEL WIRE W/ WINDSHIELD WIPER, SLIDING SUNROOF W/O SLIDING SUNROOF W/O WINDSHIELD WIPER WHT WIRE WHT/BLU WIRE WHT/GRY WIRE
