Cooling fan circuit for Buick Envision II (2020-2024)

BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/WHT WIRE BLK/YEL WIRE BLOCK ENGINE COOLANT FLOW CONTROL VALVE BLU WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/YEL WIRE COMPUTER DATA LINES SYSTEM COOLANT DIVERTER VALVE ACTUATOR CONTROL CLOSE COOLANT DIVERTER VALVE ACTUATOR CONTROL OPEN COOLANT DIVERTER VALVE POS SIG COOLANT TEMP SENS 2 SIG ENG BLOCK COOLANT TEMP SIG ENG CTRL MOD LIN BUS 1 ENG CTRL MOD LIN BUS 2 ENG CTRL SENS LO REF 1 ENG CTRL VEHICLE SENS 5 VOLT REF 1 ENG CTRL VEHICLE SENS LOW REF 1 ENG INLET COOLANT TEMP SIG ENG INTEGRATED EXHAUST MANIFOLD TEMP SIG ENG OUTLET COOLANT TEMP SIG ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) ENGINE CONTROLS SYSTEM ENGINE COOLANT BYPASS VALVE ENGINE COOLANT TEMPERATURE SENSOR 1 ENGINE COOLANT TEMPERATURE SENSOR 2 ENGINE COOLANT TEMPERATURE SENSOR 5 ENGINE COOLANT TEMPERATURE SENSOR 6 ENGINE CTRL SENS LOW REF 2 ENGINE WIRING HARNESS JUNCTION BLOCK GRN/BRN WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/VIO WIRE HOT W/ ENGINE CONTROLS IGNITION RELAY ENERGIZED LEFT FRONT STRUT TOWER) LOGIC RUN/CRANK IGN 1 VOLT SIGNAL GROUND VIO WIRE VIO/BLU WIRE VIO/WHT WIRE WHT/RED WIRE YEL/BLK WIRE YEL/BLU WIRE

1 VOLT AUTOSAR CAN BUS BLK WIRE BLK/GRY WIRE BLU/WHT WIRE BLU/YEL WIRE COMPUTER DATA LINES SYSTEM COOLING FAN MOTOR ENGINE COOLANT PUMP ENGINE COOLANT TEMPERATURE GAUGE ENGINE WIRING HARNESS JUNCTION BLOCK GRN/BRN WIRE GRN/VIO WIRE GROUND HOT AT ALL TIMES HOT W/ IGNITION MAIN RELAY ENERGIZED INSTRUMENT PANEL CLUSTER CONTROL MODULE INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK LOGIC NCA WIRE RADIATOR COOLANT TEMPERATURE SENSOR RED/GRY WIRE RED/YEL WIRE RIGHT SIDE OF RADIATOR) RUN/CRANK IGN VIO/BLK WIRE VIO/WHT WIRE YEL/BLK WIRE
