Buick Envision II (2020-2024) transmission output shaft speed Wiring diagram
This page shows the only wiring diagram for the component.transmission output shaft speed, which is found in the car Buick Envision II (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transmission output shaft speed (1 of 1)
AUTOMATIC TRANSMISSION
AUTOSAR CAN BUS (+) 2 SERIAL DATA
BATTERY
BATTERY DISTRIBUTION ENGINE COMPARTMENT FUSE BLOCK
BATTERY MONITOR MODULE
BLK WIRE
BLU/YEL WIRE
COMPUTER DATA LINES SYSTEM
ELECTRONIC TRANSMISSION RANGE SELECT OUT OF PARK SWITCH 2 SIGNAL
ELECTRONIC TRANSMISSION RANGE SELECT OUT OF PARK SWITCH SIGNAL
ENGINE RESTART RELAY
ENGINE WIRING HARNESS JUNCTION BLOCK
GENERATOR
HOT AT ALL TIMES
NCA WIRE
RED/WHT WIRE
STARTER
STARTER RELAY
TRANSMISSION CONTROL MODULE (TOP OF TRANSMISSION)
TRANSMISSION OUTPUT SHAFT SPEED
TRANSMISSION PARK VALVE POSITION SWITCH
TRANSMISSIONS SYSTEM
VIO/WHT WIRE
VIO/YEL WIRE
WHT WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Starting circuit (1 of 2) -> TRANSMISSION OUTPUT SHAFT SPEED
