Buick Envision II (2020-2024) trans output shaft spd Wiring diagram
This page shows the only wiring diagram for the component.trans output shaft spd, which is found in the car Buick Envision II (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trans output shaft spd (1 of 1)
AUTOMATIC TRANSMISSION
AUTOMATIC TRANSMISSION INPUT SPEED SENSOR
AUTOMATIC TRANSMISSION OUTPUT SPEED SENSOR
AUTOSAR CAN BUS (+) 2 SERIAL DATA AUTOSAR CAN BUS (-) 2 SERIAL DATA
BLK/VIO WIRE
BLK/WHT WIRE
BLU/YEL WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CANCEL SWITCH
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SWITCH
CRUISE IND
CRUISE SWITCH
ENGINE WIRING HARNESS JUNCTION BLOCK
FORWARD COLLISION WARNING SWITCH
GRN/VIO WIRE
GRN/YEL WIRE
GRY/BLU WIRE
GRY/GRN WIRE
HEATED STEERING WHEEL IND
HEATED STEERING WHEEL SWITCH
HOT AT ALL TIMES
INPUT SPD SIG
LOGIC
NCA WIRE
OUTPUT SPD SIG
RED/GRN WIRE
RED/GRY WIRE
RES+
SEATS SYSTEM
SET-
STEERING WHEEL AIR BAG COIL
STEERING WHEEL RADIO CONTROL SWITCH
TRANS INPUT SHAFT SPD
TRANS INTER SPD SIG
TRANS OUTPUT SHAFT SPD
TRANSMISSION CONTROL MODULE (TOP OF TRANSMISSION)
TRANSMISSIONS SYSTEM
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Cruise control circuit (2 of 2) -> TRANS OUTPUT SHAFT SPD
