Buick Envision II (2020-2024) rr closure unlatch actr unlatch ctrl Wiring diagram
This page shows the only wiring diagram for the component.rr closure unlatch actr unlatch ctrl, which is found in the car Buick Envision II (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rr closure unlatch actr unlatch ctrl (1 of 1)
AUTOSAR CAN
BATT POS VOLT
BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY CONTROL MODULE
BUS (-) 2 SERIAL DATA
CAN BUS (+) 2
COMPUTER DATA LINES SYSTEM
DOOR LOCKS SYSTEM
GRN/YEL WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LIFTGATE AJAR SW SIG 1
LIFTGATE LATCH
LIGHTING CONTROL MODULE
LOCK ACTUATORS UNLOCK CTRL 2
REAR LICENSE PLATE LAMP MODULE
RED/WHT WIRE
RR CLOSURE HNDL SW OPEN SIG
RR CLOSURE UNLATCH ACTR UNLATCH CTRL
VIO/GRY WIRE
WHT WIRE
YEL/BLU WIRE
Go to component -> Liftgate release circuit -> RR CLOSURE UNLATCH ACTR UNLATCH CTRL
