Buick Envision II (2020-2024) right park brake motor apply ctrl Wiring diagram
This page shows the only wiring diagram for the component.right park brake motor apply ctrl, which is found in the car Buick Envision II (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right park brake motor apply ctrl (1 of 1)
AUTOSAR CAN BUS (+) 5 SERIAL DATA
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/YEL WIRE
BRAKE MASTER CYLINDER)
BRAKE SYSTEM CONTROL MODULE
CAN BUS (-) 1 SERIAL DATA
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
GRN/VIO WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
HOT W/ BATTERY SAVER RELAY 1 ENERGIZED
HOT W/ IGNITION MAIN RELAY 1 ENERGIZED
IGN 1 VOLT
INSTRUMENT PANEL CLUSTER CONTROL MODULE
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LEFT FRONT STRUT TOWER)
LEFT PARK BRAKE MOTOR APPLY CTRL
LEFT PARK BRAKE MOTOR LOW REF
LEFT REAR PARKING BRAKE ACTUATOR
LOGIC
PARK BRAKE IND
PARKING BRAKE CONTROL SWITCH
RED/GRY WIRE
RIGHT PARK BRAKE MOTOR APPLY CTRL
RIGHT PARK BRAKE MOTOR LOW REF
RIGHT REAR PARKING BRAKE ACTUATOR
RUN/CRANK IGN 1 VOLTAGE
SERVICE PARK BRAKE IND
VIO/BLK WIRE
VIO/GRY WIRE
WHT WIRE
Go to component -> Park brake system circuit -> RIGHT PARK BRAKE MOTOR APPLY CTRL
