Buick Envision II (2020-2024) passenger outside rear view mirror actuator Wiring diagram
This page shows the only wiring diagram for the component.passenger outside rear view mirror actuator, which is found in the car Buick Envision II (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger outside rear view mirror actuator (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BRN/GRY WIRE
BRN/WHT WIRE
COAX
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DRIVER FRONT SEAT ADJUSTER MEMORY SWITCH
DRIVER SEAT ADJUSTER MEMORY MODULE
ENGINE WIRING HARNESS JUNCTION BLOCK
EXIT
GRN WIRE
GRN/BLK WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
LOGIC
MIRROR DIMMING
MIRRORS SYSTEM
NAVIGATION SYSTEM
NCA WIRE
PASSENGER FRONT SIDE DOOR WINDOW SWITCH
PASSENGER OUTSIDE REAR VIEW MIRROR
PASSENGER OUTSIDE REAR VIEW MIRROR ACTUATOR
PASSENGER OUTSIDE REAR VIEW MIRROR GLASS
PASSENGER SIDE OBJECT DETECTION INDICATOR
RED/GRN WIRE
RED/WHT WIRE
RIGHT SIDE VIEW DRIVER INFORMATION CAMERA
SET-
VIO/WHT WIRE
WHT WIRE
YEL/RED WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Memory mirrors circuit (2 of 2) -> PASSENGER OUTSIDE REAR VIEW MIRROR ACTUATOR
