Buick Envision II (2020-2024) lf advanced parking assist side object sens sig Wiring diagram

AUTOSAR CAN BUS AUTOSAR CAN BUS (+) 1 SERIAL DATA AUTOSAR CAN BUS (+) 2 SERIAL DATA BATT POS VOLT BLK/BLU WIRE BLK/GRY WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER INFORMATION CENTER DISPLAY FRT PARKING ASSIST DISPLAY CONTROL GRN WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER CONTROL MODULE INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK LEFT FRONT ADVANCED PARKING ASSIST ALARM SENSOR LEFT FRONT MIDDLE PARKING ASSIST ALARM SENSOR LEFT FRONT OUTER PARKING ASSIST ALARM SENSOR LF ADVANCED PARKING ASSIST SIDE OBJECT SENS SIG LF MIDDLE PARKING ASSIST SENS LF OUTER PARKING ASSIST SENS LOGIC LR ADVANCED PARKING ASSIST SIDE OBJECT SENS SIG LR MIDDLE PARKING ASSIST SENS SIG LR OUTER PARKING ASSIST SENS SIG OBJECT SENS LOW REF OBJECT SENS VOLT REF PARKING ASSIST CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT) RED/BRN WIRE RF MIDDLE PARKING ASSIST SENS RF OUTER PARKING ASSIST SENS RIGHT FRONT ADVANCED PARKING ASSIST ALARM SENSOR RIGHT FRONT MIDDLE PARKING ASSIST ALARM SENSOR RIGHT FRONT OUTER PARKING ASSIST ALARM SENSOR RR ADVANCED PARKING ASSIST SIDE OBJECT SENS SIG RR MIDDLE PARKING ASSIST SENS SIG RR OUTER PARKING ASSIST SENS SIG VIO/GRY WIRE VIO/WHT WIRE WHT WIRE WHT/GRY WIRE YEL WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/VIO WIRE YEL/WHT WIRE
