Buick Envision II (2020-2024) front sunroof sunshade motor wiring diagram
This page shows the only wiring diagram for the component.front sunroof sunshade motor, which is found in the car Buick Envision II (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
front sunroof sunshade motor wiring diagram (1 of 1)
B+ POS SNS LOW REF
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ENGINE WIRING HARNESS JUNCTION BLOCK
FRNT SUNSHADE SW SIG
FRONT SUNROOF SUNSHADE MOTOR
FRT SS MTR OPEN CTRL FRT SUNSHADE MTR CLS CNTRL
GRN WIRE
GRN/WHT WIRE
GROUND
HOT AT ALL TIMES
LIN BUS 8
LOGIC
POS SNS HIGH REF
RED WIRE
RED/YEL WIRE
ROOF CONSOLE
SLIDE
SUNROOF CONTROL MODULE (FRONT OF SUNROOF)
TILT
WHT WIRE
Go to component -> Power top/sunroof circuit -> FRONT SUNROOF SUNSHADE MOTOR
