Buick Envision II (2020-2024) day night led ctrl Wiring diagrams

AUTOSAR CAN BUS (+) 1 SERIAL DATA AUTOSAR CAN BUS (+) 2 SERIAL DATA AUTOSAR CAN BUS (+) 5 SERIAL DATA AUTOSAR SERIAL DATA CAN BUS (-) 8 SERIAL DATA BATT POS VOLT BLK/WHT WIRE BLU WIRE BLU/GRY WIRE BLU/WHT WIRE BLU/YEL WIRE COMPUTER DATA LINES SYSTEM DAY NIGHT LED CTRL DRIVER INFORMATION CENTER DISPLAY FORWARD COLLISION ALERT DISPLAY FORWARD COLLISION ALERT LED CTRL GRY/BLK WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ IGNITION MAIN RELAY ENERGIZED IMAGE PROCESSING MODULE (LEFT SIDE OF LUGGAGE COMPT) INSTRUMENT PANEL CLUSTER CONTROL MODULE INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK LOGIC LONG RANGE FORWARD RANGE RADAR SENSOR RED/YEL WIRE SIG GND VIO/GRN WIRE WHT WIRE WHT/GRY WIRE

BATTERY POSITIVE VOLTAGE BLK WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/GRY WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BODY CONTROL MODULE BRN WIRE COMPUTER DATA LINES SYSTEM CRUISE CONTROL SWITCH DAY NIGHT LED CTRL DRIVER INFORMATION CENTER DISPLAY DRIVER SEAT ADJUSTER MEMORY MODULE FLOOR CONSOLE ACCESSORY FUNCTION SWITCH FORWARD COLLISION ALERT DISPLAY FORWARD COLLISION ALERT LED CTRL GRN WIRE GRY/BLK WIRE GRY/GRN WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ IGNITION MAIN RELAY ENERGIZED INSTRUMENT CLUSTER CONTROL MODULE INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK LANE DEPARTURE WARN DISABLE SW SIG LANE DEPARTURE WARN IND CTRL LANE DEPARTURE WARNING IND LANE KEEPING ASSIST IND LANE KEEPING ASSIST SWITCH LEFT FRONT SEAT LANE DEPARTURE WARNING ACTUATOR LOGIC LR SEAT HAPTIC MOVEMENT MOTOR CONTROL NCA WIRE RED WIRE RED/BRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT SEAT LANE DEPARTURE WARNING ACTUATOR STEERING WHEEL AIR BAG COIL VEHICLE AHEAD IND VIO WIRE VIO/GRN WIRE W/ MEMORY W/O MEMORY WHT WIRE WHT/GRY WIRE WINDSHIELD FRONT VIEW CAMERA YEL WIRE YEL/BRN WIRE
