Buick Envision I (2016-2018) sol rly ctrl Wiring diagrams
This page contains all the electrical diagrams for the component. sol rly ctrl, in which he is found in the car Buick Envision I (2016-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram sol rly ctrl (1 of 2)
ACC WAKEUP SERIAL DATA
BATT POS VOLT
BCM 2 FUSE
BCM 6 FUSE
BCM 7 FUSE
BCM 8 FUSE
BLK WIRE
BLU/BLK WIRE
BODY CONTROL MODULE
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY AUTOMATIC TRANSMISSION ASSEMBLY
DATA LINK CONNECTOR
DLC FUSE
ENGINE CONTROL MODULE
FROM BATTERY FUSE BLOCK (DIAGRAM 1 OF 9)
FROM UNDERHOOD FUSE BLOCK (DIAGRAM 1 OF 9)
GROUND
HVAC CONTROL MODULE
HVAC FUSE
IGN FUSE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
INSTRUMENT PANEL FUSE BLOCK
KEYLESS ENTRY CONTROL MODULE
L/GATE RELSE FUSE
LEFT STEERING WHEEL CONTROLS SWITCH
OCC SNSR FUSE
PASSENGER PRESENCE MODULE
PEPS FUSE
POWER SUPPLY TRANSFORMER (LOWER CENTER OF INSTRUMENT PANEL)
REAR BODY FUSE BLOCK
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT STEERING WHEEL CONTROLS SWITCH
RUN/CRANK IGN 1 VOLT
SDM FUSE
SERIAL DATA (+) (3)
SOL RLY CTRL
STARTER RELAY
STEERING WHEEL AIR BAG COIL
STR/WHL/CNTRL FUSE
TCM FUSE
TO INSTRUMENT PANEL FUSE BLOCK (DIAGRAM 4 OF 9)
UNDERHOOD FUSE BLOCK
VIDEO PROCESSING CONTROL MODULE
VIO/GRN WIRE
VIO/YEL WIRE
WHT WIRE
YEL/VIO WIRE
Go to component -> Power distribution circuit (3 of 9) -> SOL RLY CTRL
Wiring diagram sol rly ctrl (2 of 2)
ACC WAKEUP SERIAL DATA
AUTOMATIC TRANSMISSION ASSEMBLY
BATT POS VOLT
BATTERY
BATTERY FUSE BLOCK
BATTERY SENSOR MODULE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BODY CONTROL MODULE
CHARGING CIRCUIT
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
DC DC TRANS FUSE
ECM, TCM FUSE
ENGINE CONTROL MODULE
FUSE 1
FUSE 5
FUSE 6
GMLAN SERIAL DATA - 1
GROUND
HOT W/ ENGINE CONTROLS IGNITION RELAY ENERGIZED
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGN 1 VOLT
IGN MODE SW VOLT
IGNITION MODE SWITCH
LOGIC
NON/ WALK FUSE
PARK/NEUTRAL SIG (1)
POWER DISTRIBUTION SYSTEM
POWER SUPPLY TRANSFORMER (LOWER CENTER OF INSTRUMENT PANEL)
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/YEL WIRE
RLY CTRL
RUN/CRANK IGN 1 VOLT
SERIAL DATA (+) (3)
SIG GND
SOL RLY CTRL
STARTER 1 FUSE
STARTER 2 FUSE
STARTER MOTOR
STARTER PINION SOLENOID ACTUATOR RELAY
STARTER RELAY
TRANS PARK/ NEUTRAL SIG 1
TRANSMISSION CONTROL MODULE
TRANSMISSION INTERNAL MODE SWITCH
UNDERHOOD FUSE BLOCK
VAR/ FUNC FUSE
VIO/BLU WIRE
VIO/GRN WIRE
VIO/YEL WIRE
WHT WIRE
WHT/GRY WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Starting circuit -> SOL RLY CTRL
