Buick Envision I (2016-2018) passive start sw sig 2 low reference Wiring diagram
This page shows the only wiring diagram for the component.passive start sw sig 2 low reference, which is found in the car Buick Envision I (2016-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passive start sw sig 2 low reference (1 of 1)
2.0L TURBO
2.5L 2.0L TURBO
A/C COMPRESSOR CLUTCH RELAY
ACC IND
ACC LED SIG
ACCESSORY IGN VOLT
ACCESSORY VOLT
BLK WIRE
BLK/GRY WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BODY CONTROL MODULE
BRN/BLK WIRE
ENGINE CONTROL MODULE
ENGINE OIL PRESSURE CONTROL SOLENOID VALVE
EVAPORATIVE EMISSION PURGE SOLENOID VALVE
GRN/BLK WIRE
GRY/GRN WIRE
HEATED OXYGEN SENSOR 1
IGN 1 VOLT
IGN MODE SW
IGNITION MODE SWITCH
ILLU IND
KEYLESS ENTRY CONTROL MODULE
NCA WIRE
NON/WALK FUSE
PASSIVE START SW SIG 2
PASSIVE START SW SIG 2 LOW REFERENCE
PASSIVE START SWITCH
RAP RELAY 2 COIL CONTROL
RUN/CRANK
RUN/CRANK IGN 1 VOLT
START IND
START LED SIG
STARTER RELAY
TO INSTRUMENT PANEL FUSE BLOCK (DIAGRAM 9 OF 9)
TRANSMISSION SHIFT LEVER POSITION INDICATOR
TURBOCHARGER BYPASS SOLENOID VALVE
TURBOCHARGER WASTEGATE SOLENOID VALVE
UNDERHOOD FUSE BLOCK
VIO WIRE
VIO/BLK WIRE
VIO/BLU WIRE
VIO/YEL WIRE
VOLT
YEL WIRE
Go to component -> Power distribution circuit (8 of 9) -> PASSIVE START SW SIG 2 LOW REFERENCE
