Buick Envision I (2016-2018) pass htd back element low ref wiring diagram
This page shows the only wiring diagram for the component.pass htd back element low ref, which is found in the car Buick Envision I (2016-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
pass htd back element low ref wiring diagram (1 of 1)
BATT POS VOLT
BLK WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLU WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
DRIVER BACK SEAT HEATING ELEMENT
DRIVER CUSHION SEAT HEATING ELEMENT
DRV HTD BACK ELEMENT CTRL
DRV HTD SEAT ELEMENT CTRL
FRONT SEAT HEATING CONTROL MODULE
GRN/BLU WIRE
HOT AT ALL TIMES
HTD/SEAT FRT FUSE
HTD/SEAT FUSE
INSTRUMENT PANEL FUSE BLOCK
LH CLIMATE CTRL BLOWER MTR SPD CTRL
LOCAL INTERCONNECT NETWORK SERIAL DATA BUS 2
PASS HTD BACK ELEMENT LOW REF
PASS HTD SEAT ELEMENT CTRL
PASSENGER BACK SEAT HEATING ELEMENT
PASSENGER CUSHION SEAT HEATING ELEMENT
RED/GRY WIRE
RED/WHT WIRE
RH CLIMATE CTRL BLOWER MTR SPD CTRL
UNDERHOOD FUSE BLOCK
VIO/BLU WIRE
YEL WIRE
Go to component -> Front heated seats circuit (1 of 2) -> PASS HTD BACK ELEMENT LOW REF
