Buick Envision I (2016-2018) infotainment face plate control module Wiring diagram
This page shows the only wiring diagram for the component.infotainment face plate control module, which is found in the car Buick Envision I (2016-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram infotainment face plate control module (1 of 1)
AUXILIARY AUDIO INPUT
BATTERY SAVER RELAY 2
BLK WIRE
CONNECTOR
DRIVER BACK SEAT BLOWER MOTOR
DRIVER BACK SEAT HEATING ELEMENT
DRIVER CUSHION SEAT BLOWER MOTOR
DRIVER CUSHION SEAT HEATING ELEMENT
DRIVER LEFT REAR SEAT HAPTIC MOVEMENT MOTOR
DRIVER RIGHT REAR SEAT HAPTIC MOVEMENT MOTOR
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT LUMBAR SUPPORT PUMP
DRIVER SEAT LUMBAR SUPPORT SWITCH
DRIVER SEAT MEMORY CONTROL MODULE
FRONT, REAR PARKING ASSIST CONTROL MODULE
HUMAN MACHINE INTERFACE CONTROL MODULE
INFOTAINMENT FACE PLATE CONTROL MODULE
INSTRUMENT PANEL MULTI- FUNCTION SWITCH
KEYLESS ENTRY CONTROL MODULE
LEFT TRAILER STOP/TURN SIGNAL LAMP RELAY
NCA WIRE
POWER SUPPLY TRANSFORMER
RADIO
RIGHT TRAILER STOP/TURN SIGNAL LAMP RELAY
STEERING WHEEL HEATER RELAY
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE
USB RECEPTACLE
W/ FORWARD COLLISION ALERT
W/ MEMORY
W/O MEMORY
WHT WIRE
Go to component -> Ground distribution circuit (7 of 8) -> INFOTAINMENT FACE PLATE CONTROL MODULE
