Buick Envision I (2016-2018) driver cooled seat switch Wiring diagram
This page shows the only wiring diagram for the component.driver cooled seat switch, which is found in the car Buick Envision I (2016-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver cooled seat switch (1 of 1)
BLK WIRE
CD/ST/VNT/ ESTAT-TCM FUSE
COMPUTER DATA LINES SYSTEM
DR/SEAT/ VENT FUSE
DRIVER BACK SEAT BLOWER MOTOR
DRIVER COOLED SEAT SWITCH
DRIVER CUSHION SEAT BLOWER MOTOR
DRIVER CUSHION, BACK SWITCH
GRN/YEL WIRE
HIGH HEAT IND
HOT W/ IGNITION MAIN RELAY ENERGIZED
HVAC CONTROLS
IGN 1 VOLT
LOCAL INTERCONNECT NETWORK SERIAL DATA BUS 9
LOGIC
LOW HEAT IND
MED HEAT IND
MTR SPD CTRL
PASSENGER BACK SEAT BLOWER MOTOR
PASSENGER COOLED SEAT SWITCH
PASSENGER CUSHION SEAT BLOWER MOTOR
PASSENGER CUSHION/ BACK SWITCH
PPL/WHT WIRE
UNDERHOOD FUSE BLOCK
VIO/BLK WIRE
VIO/BLU WIRE
VIO/WHT WIRE
YEL WIRE
Go to component -> Front heated seats circuit (2 of 2) -> DRIVER COOLED SEAT SWITCH
