Buick Encore I (2012-2016) sw sig rr dr ajar wiring diagram
This page shows the only wiring diagram for the component.sw sig rr dr ajar, which is found in the car Buick Encore I (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
sw sig rr dr ajar wiring diagram (1 of 1)
1 17 5 9 SIG GND HAZARD LED DIMG SIG IND DIMMING CTRL LIGHTING CTR SW SIG
19 4 CHILD LOCKOUT IND LIGHTING CTR SW REFR
5 7 LIFTGATE AJAR SW SIG 1 LED AMBIENT LIGHTING CTRL 1
9 1 2 7 DIMMING CTRL INTERIOR LMP CTRL INADVERTENT POWER CTRL TRUNK LAMP CTRL
BATT POSITIVE VOLT
BCM 8 FUSE
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH)
CHILD SECURITY LOCK SWITCH
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
DIMMER SW
FR FOG LP SW
FUEL ECONOMY MODE SWITCH
GRN/GRY WIRE
GRN/YEL WIRE
GRY WIRE
GRY/YEL WIRE
HEADLAMP SWITCH
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK (BEHIND LEFT END OF DASH)
LED BACKLIGHT DIMG CTRL
LEFT REAR DOOR LATCH ASSEMBLY
LEFT REAR WINDOW SWITCH
LOGIC
LR DR AJAR SW SIG
NETWORK BUS 3
NETWORK BUS 4
RED/YEL WIRE
RIGHT REAR DOOR LATCH ASSEMBLY
RIGHT REAR WINDOW SWITCH
RR FOG LP SW
SW SIG RR DR AJAR
SWC BKLT FUSE
VIO/GRY WIRE
W/ START/ STOP
W/O START /STOP
WHT WIRE
WHT/BRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Interior lights circuit (1 of 3) -> SW SIG RR DR AJAR
