Buick Encore I (2012-2016) sig mtr status lf dr ajar sw Wiring diagram
This page shows the only wiring diagram for the component.sig mtr status lf dr ajar sw, which is found in the car Buick Encore I (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sig mtr status lf dr ajar sw (1 of 1)
BLK WIRE
COMPUTER DATA LINES SYSTEM
DOME LAMP
DOME/READING LAMPS
DRIVER DOOR LATCH ASSEMBLY
DRIVER DOOR LOCK SWITCH
DRIVER DR LOCK MTR STATUS
DRIVER WINDOW SWITCH
GRN/GRY WIRE
GRN/YEL WIRE
GRY WIRE
LEFT SUNSHADE (TOP LEFT SIDE OF WINDSHIELD)
LOGIC
NETWORK BUS 3
OUTSIDE REARVIEW MIRROR SWITCH
PASSENGER DOOR LATCH ASSEMBLY
PASSENGER DOOR LOCK SWITCH
PASSENGER WINDOW SWITCH
REAR COMPARTMENT COURTESY LAMP
RIGHT SUNSHADE (TOP RIGHT SIDE OF WINDSHIELD)
SIG LF DR AJAR SW
SIG MTR STATUS LF DR AJAR SW
SUNROOF SWITCH
SUNROOF TILT SWITCH
W/ SLIDING
WHT/BRN WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Interior lights circuit (3 of 3) -> SIG MTR STATUS LF DR AJAR SW
