Buick Encore I (2012-2016) sig ground Wiring diagram
This page shows the only wiring diagram for the component.sig ground, which is found in the car Buick Encore I (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sig ground (1 of 1)
3 11 B+ TAP UP/TAP DOWN SW SIG
6 13 PARK LOCK SOL CTRL SHIFT POS SIG
AC APO/ PRNDL FUSE 21
ACCESSORY VOLTAGE
BCM 5 FUSE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
COIL CONTROL
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
GRN WIRE
GRN/BLU WIRE
GRY/VIO WIRE
HIGH SPEED GMLAN SERIAL DATA (+)
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
HOT W/ RETAINED ACCESSORY POWER RELAY ENERGIZED
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK (BEHIND LEFT END OF DASH)
KEY CAPTURE SOLENOID ACTUATOR
LOGIC
LOW SPEED GMLAN SERIAL DATA
NETWORK BUS 2
PARK POSITION SWITCH
POWER DISTRIBUTION SYSTEM
RAP RELAY
RED/GRY WIRE
SIG GROUND
TCM R/C FUSE
TRANSMISSION MANUAL SHIFT SWITCH
TRANSMISSION SHIFT LEVER
TRANSMISSION SHIFT LEVER POSITION INDICATOR
TRANSMISSION SHIFT LOCK CONTROL SOLENOID ACTUATOR
UNDERHOOD FUSE BLOCK (LEFT FRONT CORNER OF ENGINE COMPT)
VIO WIRE
VIO/BLK WIRE
VIO/YEL WIRE
WHT WIRE
WHT/VIO WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> A/t circuit (2 of 2) -> SIG GROUND
