Buick Encore I (2012-2016) passenger outside rear view mirror Wiring diagram
This page shows the only wiring diagram for the component.passenger outside rear view mirror, which is found in the car Buick Encore I (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger outside rear view mirror (1 of 1)
APPROXIMATELY
BLK WIRE
BLK/BRN WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
DRIVER OUTSIDE REAR- VIEW MIRROR
GMLAN LO SPD
GRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRY/BRN WIRE
GRY/YEL WIRE
IGN 1
INSTRUMENT CLUSTER
LAMP
LEFT FRONT PARK LAMP
LEFT FRONT SIDE MARKER LAMP
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLAMP ASSEMBLY
LEFT TURN IND
LEFT TURN SIGNAL REPEATER LAMP
LOGIC
NCA WIRE
OF ENGINE COMPT)
PARK LAMP IND
PASSENGER OUTSIDE REAR VIEW MIRROR
RIGHT FRONT SIDE MARKER LAMP RIGHT FRONT PARK LAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP ASSEMBLY
RIGHT TURN IND
RIGHT TURN SIGNAL REPEATER
SER DATA
UNDERHOOD FUSE BLOCK (LEFT FRONT CORNER
VIO/BLK WIRE
VIO/BLU WIRE
VIO/GRY WIRE
VOLT
W/ MANUAL FOLDING MIRRORS
WHT WIRE
WHT/GRN WIRE
WHT/YEL WIRE
Go to component -> Exterior lamps circuit (2 of 3) -> PASSENGER OUTSIDE REAR VIEW MIRROR
