Buick Encore I (2012-2016) l/gate rly fuse Wiring diagrams
This page contains all the electrical diagrams for the component. l/gate rly fuse, in which he is found in the car Buick Encore I (2012-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram l/gate rly fuse (1 of 2)
BCM RVC FUSE
BLK WIRE
BLK/WHT WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
ENDGATE LATCH RELAY COIL CONTROL
ENDGATE LATCH RELAY SUPPLY VOLTAGE
GRN WIRE
GRN/BRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK (BEHIND LEFT END OF DASH)
L/GATE RLY FUSE
LIFTGATE AJAR SWITCH SIGNAL 1
LIFTGATE LATCH (BOTTOM CENTER OF LIFTGATE)
LIFTGATE UNLATCH RELAY
LIFTGATE UNLATCH SWITCH
LOGIC
LOW SPEED GMLAN SERIAL DATA
REAR CLOSURE HANDLE SWITCH OPEN SIGNAL
RED/GRY WIRE
SIGNAL GROUND
VIO/GRY WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Liftgate release circuit -> L/GATE RLY FUSE
Wiring diagram l/gate rly fuse (2 of 2)
AFL MDL FUSE
AOS DISPLAY HDLP SW/ AFL/DC CVT
BATTERY FUSE BLOCK (TOP OF FUSE BATTERY)
BCM 1 BCM 2 BCM 3 BCM 4 FUSE BCM 5 FUSE FUSE FUSE FUSE
BCM 6 FUSE BCM 7 FUSE
BCM 8 FUSE 4 OF 6)
BCM RVC FUSE
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
DATA LINK CONNECTOR
DLC FUSE
DRIVER WINDOW MOTOR
FROM BCM 8 FUSE (DIAGRAM 4 OF 6)
FROM FUSE 4 (DIAGRAM 1 OF 6)
FROM UNDERHOOD FUSE BLOCK (DIAGRAM 2 OF 6)
FRONT, REAR PARKING ASSIST CONTROL MODULE
FUSE FUSE
GRN WIRE
GRY WIRE
HVAC CONTROLS
HVAC DRIVER CONTROL WINDOW MODULE SWITCH
HVAC MDL PWR WNDW SW DR HVAC ICSI FUSE FUSE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK (BEHIND LEFT END OF DASH)
IPC/PTC/CTRL/ CLUTCH SW FUSE FROM AFL MDL FUSE (DIAGRAM 4 OF 6)
L/GATE RLY FUSE
LDW MDL (DIAGRAM 6 OF 6) ISRVM FUSE
LEFT REAR WINDOW SWITCH
LIFTGATE UNLATCH RELAY
PASSENGER WINDOW SWITCH
POWER SUPPLY TRANSFORMER (W/ START/ STOP)
PWR WNDW MTR FRT FUSE
PWR WNDW MTR REAR
RAIN SENSOR MODULE (W/ MOISTURE SENSITIVE PULSE WINDSHIELD WIPER SYSTEM)
RAIN SNSR FUSE
RED WIRE
SDM B+ FUSE
SPARE DLIS FUSE FUSE
SPARE FUSE
TO IGNITION SWITCH (DIAGRAM 6 OF 6)
TO L/GATE RLY FUSE (DIAGRAM
TO PWR WNDW MTR REAR (DIAGRAM 4 OF 6)
TO RETAINED ACCESSORY POWER RELAY
UPA MDL HEADLAMP FUSE LEVELING FUSE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (4 of 6) -> L/GATE RLY FUSE
