Buick Encore I (2012-2016) lane departure warning indicator Wiring diagram
This page shows the only wiring diagram for the component.lane departure warning indicator, which is found in the car Buick Encore I (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lane departure warning indicator (1 of 1)
1 2 3 4 5 6 7 8 9 10 GND
BATT +
BATT POS VOLT LANE DEPARTURE WARNING IND CTRL
BLK WIRE
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
FRONTVIEW CAMERA MODULE (FRONT CENTER OF HEADLINER)
GRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY/WHT WIRE
HOT AT ALL TIMES
IND DIMMING CTRL
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK BCM 5 (BEHIND LEFT FUSE END OF DASH)
INSTRUMENT PANEL MULTI-FUNCTION SWITCH 2
LANE DEPARTURE WARNING INDICATOR
LDW MDL ISRVM FUSE
LEFT STEERING WHEEL CONTROLS SWITCH (UNDER CENTER CONSOLE)
LO SPD GMLAN SERIAL DATA
LOGIC
LOW SPD GMLAN SER DATA BODY CONTROL MODULE (LEFT SIDE OF DASH)
RED/GRY WIRE
RED/YEL WIRE
STEERING WHEEL AIR BAG COIL (TOP OF STEERING COLUMN)
STEERING WHEEL CTRL SW
WHT WIRE
