Buick Encore I (2012-2016) ignition key resistor sig Wiring diagram
This page shows the only wiring diagram for the component.ignition key resistor sig, which is found in the car Buick Encore I (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ignition key resistor sig (1 of 1)
AC APO/PRNDL FUSE FUSE
ACCESSORY VOLTAGE
BATTERY SAVER RELAY
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
CIGAR LIGHTER RECEPTACLE
CIGAR LTR/ DC APO FUSE SPARE FUSE
CONTROL SOLENOID VALVE ASSEMBLY AUTOMATIC TRANSMISSION ASSEMBLY
ENGINE POWER SUPPLY CONTROL TRANSFORMER MODULE
FROM INSTRUMENT PANEL FUSE BLOCK (DIAGRAM 4 OF 6)
FROM LDW MDL ISRVM FUSE (DIAGRAM 4 OF 6)
GRN WIRE
GRN/VIO WIRE
GRY WIRE
IGNITION KEY RESISTOR SIG
IGNITION SWITCH
KEY-IN IGNITION SWITCH
LOG MODE ACCESSORY RLY WAKEUP OPEN SERIAL CTRL DATA
LOG MODE RLY COIL CTRL
LOGISTIC MODE RLY FUSE
OFF
OFF/RUN/CRANK VOLTAGE
RAP RLY COIL CTRL
RED WIRE
RED/VIO WIRE
RETAINED ACCESSORY POWER RELAY
RUN WIRE
RUN/CRANK IGNITION 1 VOLTAGE
RUN/CRANK RELAY COIL CTRL
SPARE SPARE CIRCUIT BREAKER 1
TO REAR BODY FUSE BLOCK (DIAGRAM 5 OF 6)
TO UNDERHOOD FUSE BLOCK (DIAGRAM 2 OF 6)
TRANSMISSION CONTROL MODULE
UNDERHOOD FUSE BLOCK (LEFT FRONT CORNER OF ENGINE COMPT)
VIO WIRE
W/ START/STOP
W/O START/STOP
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (6 of 6) -> IGNITION KEY RESISTOR SIG
