Buick Encore I (2012-2016) exhaust camshaft position sensor (left front of Wiring diagram
This page shows the only wiring diagram for the component.exhaust camshaft position sensor (left front of, which is found in the car Buick Encore I (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram exhaust camshaft position sensor (left front of (1 of 1)
A/C REFRIGERANT PRESSURE SENSOR (ON A/C COMPRESSOR)
BLK/BLU WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BRN WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/YEL WIRE
CRANKSHAFT POSITION SENSOR
EXHAUST CAMSHAFT POSITION SENSOR (LEFT FRONT OF
FUEL PRESSURE SENSOR (TOP OF ENGINE, ON END OF FUEL RAIL)
GRN WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY/BLU WIRE
GRY/WHT WIRE
GRY/YEL WIRE
INTAKE CAMSHAFT POSITION SENSOR (RIGHT FRONT OF CYLINDER HEAD)
KNOCK SENSOR (LOWER RIGHT SIDE OF ENGINE)
VIO/BLK WIRE
VIO/BLU WIRE
VIO/BRN WIRE
VIO/GRY WIRE
WHT/BLK WIRE
YEL/BLU WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 1.4l vin b (5 of 6) -> EXHAUST CAMSHAFT POSITION SENSOR (LEFT FRONT OF
