Buick Encore I (2012-2016) evaporative emission purge solenoid valve Wiring diagram
This page shows the only wiring diagram for the component.evaporative emission purge solenoid valve, which is found in the car Buick Encore I (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram evaporative emission purge solenoid valve (1 of 1)
BATTERY
BATTERY FUSE BLOCK (TOP OF BATTERY)
BATTERY SENSOR MODULE
BLU WIRE
BRAKE BOOSTER PUMP MOTOR RELAY
BRN WIRE
CHASSIS CONTROL MODULE
COLD START WINDSHIELD FUEL PUMP WIPER SPEED RELAY CONTROL RELAY
CONTROL SOLENOID VALVE ASSEMBLY AUTOMATIC TRANSMISSION ASSEMBLY
EBCM PUMP
EBCM VALVE
ECM PT IGN-1/ IGN-2 FUSE FUSE 28
ECM-B FUSE
ELECTRONIC BRAKE CONTROL MODULE
ENGINE CONTROL MODULE
ENGINE CONTROLS IGNITION RELAY
ENGINE COOLANT THERMOSTAT HEATER
EVAPORATIVE EMISSION PURGE SOLENOID VALVE
EVAPORATIVE EMISSION VENT SOLENOID VALVE
EVP FUSE FUSE
FRT WIPER FUSE
FSCM B+ FUSE
FUSE
FUSE 13
FUSE 25
FUSE FUSE
FUSE MEMORY MODULE FUSE
GENERATOR
GRN WIRE
GRY WIRE
HEATED HEATED OXYGEN OXYGEN SENSOR 1 SENSOR 2
MAF SENSOR FUSE
MULTI-FUNCTION INTAKE AIR SENSOR
NCA WIRE
OSRVM SW
OUTSIDE REARVIEW MIRROR SWITCH
RED WIRE
SEAT MEMORY CONTROL MODULE
SOLENOID FUSE
STARTER POWER MOTOR STEERING CONTROL MODULE
SUNROOF CONTROL MODULE (IF EQUIPPED)
SUNROOF FUSE
TCB B+ FUSE
TO COOL FAN HIGH FUSE (DIAGRAM 2 OF 6)
TO FUSE 3 (DIAGRAM 4 OF 6) FUSE
TO REAR BODY FUSE BLOCK
TRANSMISSION CONTROL MODULE
TURBOCHARGER BYPASS SOLENOID VALVE
TURBOCHARGER WASTEGATE SOLENOID VALVE
UNDERHOOD RELAY BLOCK (LEFT FRONT OF ENGINE COMPT)
VIO WIRE
WHT WIRE
WINDSHIELD WIPER RELAY
YEL WIRE
Go to component -> Power distribution circuit (1 of 6) -> EVAPORATIVE EMISSION PURGE SOLENOID VALVE
