Buick Encore I (2012-2016) cigarette lighter receptacle Wiring diagram
This page shows the only wiring diagram for the component.cigarette lighter receptacle, which is found in the car Buick Encore I (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cigarette lighter receptacle (1 of 1)
2 2 (W/ NAVIGATION) (W/O NAVIGATION)
AMBIENT LIGHT/ SUNLOAD SENSOR
BLK WIRE
BRAKE FLUID LEVEL SWITCH
BRN WIRE
CHILD FUEL SECURITY ECONOMY LOCK MODE SWITCH SWITCH
CIGARETTE LIGHTER RECEPTACLE
DATA LINK CONNECTOR
DRIVER DRIVER DOOR WINDOW LATCH SWITCH ASSEMBLY
DRIVER DRIVER OUTSIDE OUTSIDE REARVIEW REARVIEW MIRROR MIRROR
DRIVER SEAT DRIVER LUMBAR SEAT SUPPORT ADJUSTER SWITCH SWITCH
HEADLAMP SWITCH
HVAC RADIO CONTROLS CONTROLS
INSTRUMENT CLUSTER
INSTRUMENT PANEL MULTI-FUNCTION SWITCH 1
LEFT REAR DOOR LATCH ASSEMBLY
LEFT STEERING WHEEL CONTROLS SWITCH
LEFT TURN SIGNAL REPEATER LAMP
NCA WIRE
OUTSIDE REARVIEW DRIVER MIRROR WINDOW SWITCH MOTOR
RETAINED ACCESSORY BATTERY POWER SAVER RELAY RELAY
RIGHT INSTRUMENT PANEL ACCENT LAMP
RIGHT STEERING WHEEL CONTROLS SWITCH
RIGHT SUNSHADE
RIGHT TURN SIGNAL REPEATER LAMP
STEERING WHEEL AIR BAG COIL
STEERING WHEEL ANGLE SENSOR
STEERING WHEEL HEATER
STEERING WHEEL HEATING CONTROL MODULE
TURN SIGNAL/ MULTI- FUNCTION RADIO SWITCH
VIO WIRE
W/ AMBIENT INTERIOR LAMP (IN INSTRUMENT PANEL HARNESS, UNDER LEFT KICK PANEL)
W/ W/O START/ START/ STOP STOP SYSTEM SYSTEM
W/O MEMORY W/ MEMORY
WHT WIRE
Go to component -> Ground distribution circuit (3 of 4) -> CIGARETTE LIGHTER RECEPTACLE
