Buick Encore I (2012-2016) bluetooth wireless communication antenna Wiring diagrams

This page contains all the electrical diagrams for the component. bluetooth wireless communication antenna, in which he is found in the car Buick Encore I (2012-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram bluetooth wireless communication antenna (1 of 4)

Wiring diagram bluetooth wireless communication antenna for Buick Encore I (2012-2016) (1 of 4)

Get access

2 3 4 5 6 1251 3363 SIG GND DISPLAY DIMMING CTRL 3365 3366 3367 CAMERA SIG 2 AUDIO SIG AUDIO SIG 2 1 BATT POSITIVE V BLK WIRE BLK/GRY WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLUETOOTH WIRELESS COMMUNICATION ANTENNA BRN WIRE COAX COAX W/O ON STAR CUT SHIELD) GPS GPS/CELL GRN/YEL WIRE GRY/VIO WIRE GRY/YEL WIRE INFO DISPLAY MODULE (W/ NAVIGATION) NCA WIRE RED/WHT WIRE REMOTE ENABLE SIG TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE W/ NAVIGATION W/ NAVIGATION, ON STAR COAX W/ NAVIGATION, W/O ON STAR W/ ON STAR COAX W/O NAVIGATION W/O NAVIGATION, W/ ON STAR YEL WIRE

Go to component -> Navigation circuit, base (4 of 4) -> BLUETOOTH WIRELESS COMMUNICATION ANTENNA

Wiring diagram bluetooth wireless communication antenna (2 of 4)

Wiring diagram bluetooth wireless communication antenna for Buick Encore I (2012-2016) (2 of 4)

Get access

1 2 3 4 6 BATT POSITIVE V SIG GND DISPLAY DIMMING CTRL 14 15 16 COAX COAX 6 2 3 BUS 10 POS VOLT GND BATT + BATT POS VOLT BLK WIRE BLK/GRY WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLUETOOTH WIRELESS COMMUNICATION ANTENNA BRN WIRE BUS 10 CAMERA SIG 2 AUDIO SIG AUDIO SIG 2 1 CELLULAR PHONE NAVIGATION, DIGITAL RADIO ANTENNA COAX COAX W/O ON STAR COAX COAX W/ ON STAR CONSOLE) CUT SHIELD) DATA SHLD DISPLAY DRAIN WIRE DISPLAY SIG + GPS GPS/CELL GRN/BLU WIRE GRN/YEL WIRE GROUND GRY/GRN WIRE GRY/VIO WIRE GRY/YEL WIRE INFO DISPLAY MODULE (W/O NAVIGATION) NAV DISPLY RESET SIG NCA WIRE RADIO ANTENNA AM/FM RADIO CONTROLS (W/ NAVIGATION) RADIO CONTROLS (W/O NAVIGATION) RED/BRN WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE REMOTE ENABLE SIG SERL DATA HI SERL DATA LO STACK SIG TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE VIO WIRE W/ NAVIGATION W/ NAVIGATION, W/O ON STAR W/0 NAVIGATION, W/ ON STAR W/NAVIGATION, ON STAR COAX W/O NAVIGATION WAKE UP SIG YEL WIRE

Go to component -> Navigation circuit, premium (4 of 4) -> BLUETOOTH WIRELESS COMMUNICATION ANTENNA
