Buick Encore I (2012-2016) backup lamp sply volt Wiring diagram
This page shows the only wiring diagram for the component.backup lamp sply volt, which is found in the car Buick Encore I (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram backup lamp sply volt (1 of 1)
29 43 HI SPD GMLAN SERIAL DATA + HI SPD GMLAN SERIAL DATA -
3 22 BATT POSITIVE VOLT LO SPD GMLAN SER DATA
AUTOMATIC TRANSMISSION ASSEMBLY
BACKUP LAMP SPLY VOLT
BACKUP LP SPLY VOLT
BATT POSITIVE VOLT
BCM 5 FUSE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH)
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
ECM-B FUSE
ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
GND SIG P
GRN WIRE
GRN/WHT WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK (BEHIND LEFT END OF DASH)
LEFT BACKUP LAMP
LEFT TAILLAMP ASSEMBLY
LOGIC INSIDE REARVIEW MIRROR
LOGIC REARVIEW CAMERA (IF EQUIPPED) (CENTER OF LIFTGATE)
NCA WIRE
RED WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT BACKUP LAMP
RIGHT TAILLAMP ASSEMBLY
SIG A SIG B SIG C
SYSTEM
TRANSMISSION CONTROL MODULE (TCM)
TRANSMISSION INTERNAL MODE SWITCH
UNDERHOOD FUSE BLOCK (LEFT FRONT CORNER OF ENGINE COMPT)
WAKE UP SIG
WHT WIRE
WHT/GRY WIRE
YEL WIRE
Go to component -> Backup lamps circuit -> BACKUP LAMP SPLY VOLT
