Buick Encore I (2012-2016) 3 2 1 immobilizer sply volt network bus 11 immobilizer ret Wiring diagram
This page shows the only wiring diagram for the component.3 2 1 immobilizer sply volt network bus 11 immobilizer ret, which is found in the car Buick Encore I (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 3 2 1 immobilizer sply volt network bus 11 immobilizer ret (1 of 1)
24 25 HI SPD GMLAN (-) 1 HI SPD GMLAN (+) 1
3 2 1 IMMOBILIZER SPLY VOLT NETWORK BUS 11 IMMOBILIZER RET
BATT POSITIVE VOLT
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRY/BLK WIRE
HI SPD GMLAN (-) 1
HOOD AJAR SW SIG
IMMOBILIZER CONTROL MODULE (NEAR IGNITION SWITCH CYLINDER)
IMMOBILIZER RET
IMMOBILIZER SPLY VOLT
INSTRUMENT CLUSTER
LO SPD GMLAN
LO SPD SERIAL DATA
LOGIC
LOW REF
NETWORK BUS 11
OPEN SW SIG
RED/GRN WIRE
SECURITY INDICATOR
SIG GND
SW SIG OPEN
WHT WIRE
YEL WIRE
Go to component -> Pass-key circuit -> 3 2 1 IMMOBILIZER SPLY VOLT NETWORK BUS 11 IMMOBILIZER RET
