Buick Encore I (2012-2016) 15 17 18 20 lo spd gmlan serial data serial data comm enable Wiring diagram

15 17 18 20 LO SPD GMLAN SERIAL DATA SERIAL DATA COMM ENABLE 23 22 5986 5985 SERIAL DATA COMM ENABLE ACC WAKEUP SERIAL DATA 24 25 2501 2500 HI SPD GMLAN SERIAL DATA (-) HI SPD GMLAN SERIAL DATA (+) AWD FWD BLK WIRE BLK/WHT WIRE BLU WIRE BLU/YEL WIRE BODY CONTROL MODULE (LEFT SIDE OF DASH) BRN WIRE BUS 2 DATA LINK CONNECTOR (DLC) (LOWER LEFT SIDE OF DASH) DLC (BEHIND LEFT FUSE END OF DASH) FRONT, REAR PARKING ASSIST CONTROL MODULE (IF EQUIPPED) FRONTVIEW CAMERA MODULE (FRONT CENTER OF HEADLINER) GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE HI SPD GMLAN SERIAL DATA + HI SPD GMLAN SERIAL DATA - HOT AT ALL TIMES HVAC CONTROL MODULE (IF EQUIPPED) INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (UNDER FRONT OF CENTER CONSOLE) INSTRUMENT CLUSTER INSTRUMENT PANEL FUSE BLOCK LEFT REAR WINDOW SWITCH LEFT SIDE OBJECT SENSOR MODULE (IF EQUIPPED) LIN LIN BUS 4 LINEAR INTERCONNECT NETWORK BUS 1 LO SPD GMLAN SERIAL DATA NETWORK BUS 8 OUTSIDE REARVIEW MIRROR SWITCH PASSENGER PRESENCE MODULE (IF EQUIPPED) (UNDER FRONT OF PASSENGER'S SEAT) RADIO RAIN SENSOR MODULE (IF EQUIPPED) (BEHIND REARVIEW MIRROR) RED/BRN WIRE RIGHT REAR WINDOW SWITCH SEAT MEMORY CONTROL MODULE (UNDER DRIVER'S SEAT) STEERING ANGLE SENSOR (TOP OF STEERING COLUMN) SUNROOF CONTROL MODULE (IF EQUIPPED) (FRONT CENTER OF ROOF) TRANSMISSION SHIFT LEVER POSITION INDICATOR VIO/YEL WIRE W/ LANE DEPARTURE ACTIVITY WARNING W/ LANE DEPERTURE WARNING W/O LANE DEPERTURE WARNING W/ START/STOP WHT WIRE WHT/BLU WIRE YEL WIRE
