Buick Encore GX I (2019-2024) service park brake ind Wiring diagram
This page shows the only wiring diagram for the component.service park brake ind, which is found in the car Buick Encore GX I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram service park brake ind (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/VIO WIRE
BRAKE SYSTEM CONTROL MODULE (NEAR BRAKE BOOSTER)
BRN WIRE
COMPUTER DATA LINES SYSTEM
GND 20
GRN/VIO WIRE
GRY WIRE
GRY/BLK WIRE
GRY/GRN WIRE
GRY/RED WIRE
HI SPD GMLAN SER DATA (+) 1
HI SPD GMLAN SER DATA (-) 1 PARK BRK SW SIG
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
INSTRUMENT CLUSTER
LEFT PARK BRAKE ACTUATOR
LOGIC
LOW SPD GMLAN SER DATA 2 GND 3
LT PARK BRK MTR APPLY CTRL
LT PARK BRK MTR LOW REF
PARK BRAKE CONTROL SWITCH
PARK BRK APPLY SW SIG
PARK BRK APPLY SW VOLT REF
PARK BRK RELEASE SW SIG
PARK BRK RELEASE SW VOLT REF
PARK BRK SW SPLY VOLT
PARK IND
R PARK BRK MTR LOW REF
R PRK BRAKE MTR APPLY CTRL
RED/YEL WIRE
RIGHT PARK BRAKE ACTUATOR
RUN/ CRANK IGNITION 1 VOLT 4
SEC FUSED BATT POS VOLT 2
SERVICE PARK BRAKE IND
UNDERHOOD FUSE BLOCK
VIO/GRN WIRE
WHT WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Park brake system circuit -> SERVICE PARK BRAKE IND
