Buick Encore GX I (2019-2024) secondary fused battery pos volt 8 Wiring diagram
This page shows the only wiring diagram for the component.secondary fused battery pos volt 8, which is found in the car Buick Encore GX I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram secondary fused battery pos volt 8 (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLU/GRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER SEAT MEMORY SWITCH
EXIT
GRN WIRE
GRN/WHT WIRE
GROUND 4
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK
LIN BUS 1
LOW SPEED GMLAN SERIAL DATA
RED/BLU WIRE
RED/VIO WIRE
SEAT MEMORY CONTROL MODULE (UNDER DRIVER'S SEAT)
SEAT MEMORY SWITCH LOW REFERENCE
SEAT MEMORY SWITCH SET SIGNAL
SEAT MEMORY SWITCH SIGNAL 1
SECONDARY FUSED BATTERY POS VOLT 16
SECONDARY FUSED BATTERY POS VOLT 8
SET-
WHT WIRE
YEL WIRE
Go to component -> Driver"s memory seat circuit -> SECONDARY FUSED BATTERY POS VOLT 8
