Buick Encore GX I (2019-2024) run ign 3 Wiring diagram
This page shows the only wiring diagram for the component.run ign 3, which is found in the car Buick Encore GX I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram run ign 3 (1 of 1)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
CONTROLS SWITCH
DK GRN WIRE
GRY/ORG WIRE
HEATED STEERING WHEEL IND
HEATED STEERING WHEEL SWITCH
HI CTRL
HOT W/ IGNITION RUN RELAY ENERGIZED
INSTRUMENT PANEL FUSE BLOCK
LED CTRL
LEFT STEERING WHEEL
LO REF
LOGIC
NCA WIRE
ORG/ WIRE
RUN IGN 3
SENS SIG
STEERING WHEEL AIR BAG COIL
STEERING WHEEL HEATER
STEERING WHEEL HEATING CONTROL MODULE
SW SIG
VIO WIRE
VIO/BRN WIRE
VOLT REF
YEL/RED WIRE
Go to component -> Heated steering wheel circuit -> RUN IGN 3
