Buick Encore GX I (2019-2024) rfa transmit sig Wiring diagram
This page shows the only wiring diagram for the component.rfa transmit sig, which is found in the car Buick Encore GX I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rfa transmit sig (1 of 1)
AMBIENT LIGHT/ SUNLOAD SENSOR
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BODY CONTROL MODULE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
ENGINE CONTROL MODULE
ENGINE HOOD SWITCH
GND (-) 31
GRN/GRY WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLK WIRE
GRY/GRN WIRE
GRY/WHT WIRE
HOOD AJAR SW SIG
HOOD OPEN SWITCH SIG
HOT AT ALL TIMES
IMMOBILIZER ANTENNA
IMMOBILIZER CONTROL MODULE (UNDER CENTER CONSOLE)
IMMOBILIZER CTRL
IMMOBILIZER LIN BUS 1
IMMOBILIZER LOW REF
INSTRUMENT CLUSTER
LOGIC
LOW SPD GMLAN SERIAL DATA 2
NCA WIRE
RED/BRN WIRE
REMOTE CONTROL DOOR LOCK RECEIVER
RFA CTRL
RFA LOW REF
RFA RECEIVE SIG
RFA RECEIVER CTRL
RFA TRANSMIT SIG
SEC FUSED BATT POS VOLT 4
SECURITY INDICATOR
SECURITY INDICATOR CTRL
SERIAL DATA (-) (1)
UNDERHOOD FUSE BLOCK
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Pass-key circuit -> RFA TRANSMIT SIG
