Buick Encore GX I (2019-2024) head-up display sw low ref Wiring diagram
This page shows the only wiring diagram for the component.head-up display sw low ref, which is found in the car Buick Encore GX I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram head-up display sw low ref (1 of 1)
BATT POS VOLT
BLK/GRN WIRE
BLK/WHT WIRE
COMPUTER DATA LINES SYSTEM
ETHERNET BUS 5 (-)
GROUND
GRY/GRN WIRE
HEAD-UP DISPLAY
HEAD-UP DISPLAY SW LOW REF
HEAD-UP DISPLAY SW SIG
HEAD-UP DISPLAY SWITCH
HEADLAMP ON
HOT AT ALL TIMES
HUD
INFO
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
LOGIC
LOW SPD GMLAN SERIAL DATA 2
POWER
RADIO
RED/BRN WIRE
VIO WIRE
VIO/WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Head-up display circuit -> HEAD-UP DISPLAY SW LOW REF
