Buick Encore GX I (2019-2024) hdlp sw park lp sig Wiring diagram
This page shows the only wiring diagram for the component.hdlp sw park lp sig, which is found in the car Buick Encore GX I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hdlp sw park lp sig (1 of 1)
AMBIENT LIGHT SENS SIG
AMBIENT LIGHT/ SUNLOAD SENSOR
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (UNDER FRONT OF CENTER CONSOLE)
BRN/VIO WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
FOG LAMP RLY CTRL
FRONT FOG LAMP RELAY
FRONT FOG LAMP SW SIG
FRONT PARK LAMP CONTROL
FTP
GND (-) 31
GND 33
GRN/BRN WIRE
GRN/GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
HDLP HI BEAM RLY CTRL
HDLP SW FLASH SIG HI BEAM SELECT SW HI BEAM SIG
HDLP SW OFF SIG
HDLP SW ON SIG
HDLP SW PARK LP SIG
HEADLAMP HIGH BEAM RELAY
HI SD GMLAN SERIAL DATA (+)1
HOT AT ALL TIMES
HVAC CONTROL MODULE
LEFT DAYTIME RUNNING LAMP,
LEFT FRONT DRL CONTROL
LEFT FRONT PARK LAMP
LEFT HEADLAMP ASSEMBLY
LEFT HIGH BEAM LAMP
LEFT LOW BEAM LAMP
LH HDLP LOW BEAM CTRL
NCA WIRE
RH HDLP LOW BEAM CTRL
RIGHT FRONT DRL CONTROL
SS LOW REF
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK
WHT WIRE
WHT/BLU WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BRN WIRE
Go to component -> Headlights circuit (1 of 2) -> HDLP SW PARK LP SIG
