Buick Encore GX I (2019-2024) hdlp sw off sig Wiring diagrams

AMBIENT LIGHT SENS SIG AMBIENT LIGHT/ SUNLOAD SENSOR BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/GRY WIRE BODY CONTROL MODULE (UNDER FRONT OF CENTER CONSOLE) BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FOG LAMP RLY CTRL FRONT FOG LAMP RELAY FRONT FOG LAMP SW SIG FRONT PARK LAMP CONTROL FTP GND (-) 31 GND 33 GRN/BRN WIRE GRN/GRY WIRE GRY/BLU WIRE GRY/BRN WIRE HDLP HI BEAM RLY CTRL HDLP SW FLASH SIG HI BEAM SELECT SW HI BEAM SIG HDLP SW OFF SIG HDLP SW ON SIG HDLP SW PARK LP SIG HEADLAMP HIGH BEAM RELAY HI SD GMLAN SERIAL DATA (+)1 HOT AT ALL TIMES HVAC CONTROL MODULE LEFT DAYTIME RUNNING LAMP, LEFT FRONT DRL CONTROL LEFT FRONT PARK LAMP LEFT HEADLAMP ASSEMBLY LEFT HIGH BEAM LAMP LEFT LOW BEAM LAMP LH HDLP LOW BEAM CTRL NCA WIRE RH HDLP LOW BEAM CTRL RIGHT FRONT DRL CONTROL SS LOW REF TURN SIGNAL/ MULTI-FUNCTION SWITCH UNDERHOOD FUSE BLOCK WHT WIRE WHT/BLU WIRE WHT/VIO WIRE YEL WIRE YEL/BRN WIRE

AUTO BATT POS VOLT BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/VIO WIRE BODY CONTROL MODULE (UNDER FRONT OF CENTER CONSOLE) BRAKE SYSTEM CONTROL MODULE (NEAR BRAKE BOOSTER) BRK FLUID LEVEL SENS SIG BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR LATCH ASSEMBLY DRIVER WINDOW MOTOR GRN/BRN WIRE GRN/GRY WIRE GRN/YEL WIRE GRY WIRE GRY/RED WIRE HDLP SW OFF SIG HDLP SW ON SIG HEAD HEADLAMP SWITCH HI SPD GMLAN SER DATA (+) 1 HI SPD GMLAN SERIAL DATA (-) (1) HOT AT ALL TIMES LEFT REAR DOOR LATCH ASSEMBLY LEFT REAR WINDOW SWITCH LF DR AJAR SW SIG LOGIC LR DR AJAR SW SIG NETWORK BUS 3 NETWORK BUS 4 OFF PARK PARK BRAKE CONTROL SWITCH PRK BRK APPLY SW SIG PRK BRK APPLY SW VOLT REF PRK BRK SW SIG PRK BRK REL SW VOLT REF PRK BRK SW SUPPLY VOLT RED/BRN WIRE RED/YEL WIRE RIGHT REAR DOOR LATCH ASSEMBLY RIGHT REAR WINDOW SWITCH RR DR AJAR SW SIG SIG GND UNDERHOOD FUSE BLOCK WHT WIRE WHT/VIO WIRE YEL WIRE YEL/RED WIRE
