Buick Encore GX I (2019-2024) gnd 33 Wiring diagrams
This page contains all the electrical diagrams for the component. gnd 33, in which he is found in the car Buick Encore GX I (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
gnd 33 wiring diagram (1 of 2)
AMBIENT LIGHT SENS SIG
AMBIENT LIGHT/ SUNLOAD SENSOR
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (UNDER FRONT OF CENTER CONSOLE)
BRN/VIO WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
FOG LAMP RLY CTRL
FRONT FOG LAMP RELAY
FRONT FOG LAMP SW SIG
FRONT PARK LAMP CONTROL
FTP
GND (-) 31
GND 33
GRN/BRN WIRE
GRN/GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
HDLP HI BEAM RLY CTRL
HDLP SW FLASH SIG HI BEAM SELECT SW HI BEAM SIG
HDLP SW OFF SIG
HDLP SW ON SIG
HDLP SW PARK LP SIG
HEADLAMP HIGH BEAM RELAY
HI SD GMLAN SERIAL DATA (+)1
HOT AT ALL TIMES
HVAC CONTROL MODULE
LEFT DAYTIME RUNNING LAMP,
LEFT FRONT DRL CONTROL
LEFT FRONT PARK LAMP
LEFT HEADLAMP ASSEMBLY
LEFT HIGH BEAM LAMP
LEFT LOW BEAM LAMP
LH HDLP LOW BEAM CTRL
NCA WIRE
RH HDLP LOW BEAM CTRL
RIGHT FRONT DRL CONTROL
SS LOW REF
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK
WHT WIRE
WHT/BLU WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BRN WIRE
Go to component -> Headlights circuit (1 of 2) -> GND 33
gnd 33 wiring diagram (2 of 2)
1.2L
230 VAC OUTLET PHASE A
AUXILIARY AUDIO INPUT
BATTERY FUSE BLOCK
BATTERY SENSOR MODULE
BLK WIRE
BLU WIRE
BLU/BRN WIRE
BRAKE SYSTEM CONTROL MODULE
BRN WIRE
BRN/BLK WIRE
COOLING FAN CONTROL MODULE
COOLING FAN MOTOR
DC/AC INVERTER CTRL
ELECTRICAL AUXILIARY HEATER
ENGINE COOLANT PUMP
FROM INSTRUMENT PANEL FUSE BLOCK (DIAGRAM 5 OF 5)
FROM REAR BODY FUSE BLOCK (DIAGRAM 2 OF 5)
GND 33
GRN WIRE
GRY WIRE
GRY/VIO WIRE
HEAD-UP DISPLAY
HVAC CONTROLS
INFO DISPLAY MODULE
INSTRUMENT CLUSTER
LEFT SIDE OBJECT SENSOR MODULE
LOGIC
NCA WIRE
PARKING ASSIST CONTROL MODULE
POWER INVERTER MODULE
RADIO
RED WIRE
RIGHT SIDE OBJECT SENSOR MODULE
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE
VIDEO PROCESSING CONTROL MODULE
VIO WIRE
WHT WIRE
WINDSHIELD FRONTVIEW CAMERA
Go to component -> Power distribution circuit (3 of 5) -> GND 33
