Buick Encore GX I (2019-2024) frt side object sens sig Wiring diagram
This page shows the only wiring diagram for the component.frt side object sens sig, which is found in the car Buick Encore GX I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram frt side object sens sig (1 of 1)
BATT POS VOLT 51
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLU/BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DISABLE LED SIG
DISABLE SIG
DISABLE SW SIG
FRT PARK ASSIST SENS LOW REF
FRT SIDE OBJECT SENS SIG
GRN WIRE
GRN/BRN WIRE
GRY WIRE
GRY/GRN WIRE
HOT W/ BATTERY SAVER RELAY 1 ENERGIZED
INSTRUMENT PANEL FUSE BLOCK
LEFT FRONT MIDDLE PARKING ASSIST SENSOR
LEFT FRONT OUTER PARKING ASSIST SENSOR
LEFT FRONT SIDE PARKING ASSIST SENSOR
LF MID PARK ASSIST SENS
LF OUTER PARK ASSIST SENS
LOW SPD GMLAN SERIAL DATA
LR MIDDLE PARK ASSIST SENS SIG
LR OUTER PARK ASSIST SENS SIG OBJECT SENS SPLY VOLT
MIDDLE PARK ASSIST SENS
OBJECT SENS LOW REF
PARK ASSIST GND
PARKING ASSIST CONTROL MODULE
RED/GRN WIRE
RF MID PARK ASSIST SENS
RF OUTER PARK ASSIST SENS
RIGHT FRONT MIDDLE PARKING ASSIST SENSOR
RIGHT FRONT OUTER PARKING ASSIST SENSOR
RIGHT FRONT SIDE PARKING ASSIST SENSOR
RR MIDDLE PARK ASSIST SENS SIG
RR OUTER PARK ASSIST SENS SIG
SERIAL DATA COMMUNICATION ENABLE
VIO/GRY WIRE
VIO/WHT WIRE
W/ FRONT, REAR PARK ASSIST
W/ REAR PARK ASSIST
WHT/BLU WIRE
WHT/GRY WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Parking assistant circuit (1 of 2) -> FRT SIDE OBJECT SENS SIG
