Buick Encore GX I (2019-2024) electric/auxiliary transmission fluid pump Wiring diagram
This page shows the only wiring diagram for the component.electric/auxiliary transmission fluid pump, which is found in the car Buick Encore GX I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electric/auxiliary transmission fluid pump (1 of 1)
AUTOMATIC TRANSMISSION ASSEMBLY
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
ELECTRIC/AUXILIARY TRANSMISSION FLUID PUMP
GRN/GRY WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
NCA WIRE
RED/YEL WIRE
TRANSMISSION FLUID PRESSURE SENSOR 1
TRANSMISSION FLUID PRESSURE SENSOR 2
TRANSMISSION INTERMEDIATE SHAFT SPEED SENSOR
TRANSMISSION OUTPUT SHAFT SPEED SENSOR
UNDERHOOD FUSE BLOCK
VIO WIRE
VIO/GRY WIRE
VIO/WHT WIRE
VIO/YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
Go to component -> A/t circuit, cvt (2 of 4) -> ELECTRIC/AUXILIARY TRANSMISSION FLUID PUMP
