Buick Encore GX I (2019-2024) driver seat belt switch Wiring diagram
This page shows the only wiring diagram for the component.driver seat belt switch, which is found in the car Buick Encore GX I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver seat belt switch (1 of 1)
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU/YEL WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE IND
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
DRIVER SEAT BELT BUCKLE
DRIVER SEAT BELT SWITCH
DRV SEAT BELT SW LO REF
DRV SEAT BELT SW SIG
ETHERNET BUS 4 (-)
GMLAN SERIAL DATA 2
GRN/GRY WIRE
GRN/YEL WIRE
GRY WIRE
GRY/GRN WIRE
GRY/WHT WIRE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
INSTRUMENT CLUSTER
LOGIC
NETWORK BUS 3
ORG/BRN WIRE
ORG/VIO WIRE
PARKING ASSIST IND
PASS SEAT BELT SW LO REF
PASS SEAT BELT SW SIG
PASSENGER DOOR LATCH ASSEMBLY
PASSENGER SEAT BELT BUCKLE
PASSENGER SEAT BELT SWITCH
PASSENGER WINDOW SWITCH
RADIO
RF DR AJAR SW SIG
SEAT BELT IND
TIRE PRESSURE IND
WHT WIRE
Go to component -> Warning systems circuit (2 of 2) -> DRIVER SEAT BELT SWITCH
