Buick Encore GX I (2019-2024) automatic transmission accumulator solenoid valve Wiring diagram
This page shows the only wiring diagram for the component.automatic transmission accumulator solenoid valve, which is found in the car Buick Encore GX I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram automatic transmission accumulator solenoid valve (1 of 1)
ACCESSORY WAKEUP SERIAL DATA
ACCUMULATOR SOL
AUTOMATIC TRANSMISSION ACCUMULATOR SOLENOID VALVE
BLK/BRN WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
CLUTCH A CTRL
CLUTCH C CTRL
CLUTCH D CTRL
CLUTCH E CTRL
COMPUTER DATA LINES SYSTEM
GRN/GRY WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
HI SPD GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGN MODE SW MODE CTRL
IN SPD SIG
OUT SPD SIG
RED/YEL WIRE
RUN/CRANK IGNITION 1 VOLT
SIG GND
TCC/CLUTCH SOL CTRL
TORQUE CONV CLTH SOL VLV
TRANS CLUTCH F CTRL
TRANS CLUTCH G CTRL
TRANS CLUTCH H CTRL
TRANS HI SIDE DRV 1 SIG
TRANS HI SIDE DRV 2 SIG
TRANS INTERMEDIATE SPD SIG
TRANS OIL LVL SENS SIG
TRANS OIL TEMP SENS LO REF
TRANS OIL TEMP SENS SIG
TRANSMISSION CONTROL MODULE
TRANSMISSION INPUT SHAFT SPEED SENSOR
TRANSMISSION INPUT/INTERMEDIATE SHAFT SPEED SENSOR
TRANSMISSION INTERMEDIATE SHAFT SPEED SENSOR
UNDERHOOD FUSE BLOCK
VIO WIRE
VIO/GRY WIRE
VIO/WHT WIRE
VIO/YEL WIRE
VOLTAGE 2
WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
Go to component -> A/t circuit, 9 speed (1 of 3) -> AUTOMATIC TRANSMISSION ACCUMULATOR SOLENOID VALVE
