Buick Enclave II (2017-2021) throttle actuator ctrl open throttle actuator ctrl close Wiring diagram

2.0L TURBO 3.6L ADAPTIVE CRUISE IND APP 5 VOLT REF 2 APP LO REF (1) APP LOW REF 2 APP SIG (1) APP SIG (2) BATT POSITIVE VOLT BCM 3 FUSE BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/PPL WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE BODY CONTROL MODULE (FRONT OF CENTER CONSOLE) BRAKE APPLY SEN LOW REF BRAKE APPLY SENS CTRL BRAKE APPLY SENS SIG BRAKE PEDAL POSITION SENSOR (UNDER LEFT SIDE OF DASH) BRAKE POSITION SENS LOW REF BRAKE POSITION SENS SIG BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM CRUISE IND CRUISE/ETC/TCC BRK SIG ECM IGN FUSE ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT) GRN/WHT WIRE GRY/GRN WIRE HIGH SPD GMLAN SERIAL DATA (+) 1 HOT AT ALL TIMES HOT W/ IGNITION MAIN RELAY ENERGIZED INSTRUMENT CLUSTER INSTRUMENT PANEL FUSE BLOCK LIGHTING CTRL SW REF LOGIC LOW SPD GMLAN SERIAL DATA 2 PPL/GRY WIRE RED/GRY WIRE RUN/CRANK IGN 1 VOLT SERIAL DATA (-) (1) SET/COAST/RESUME/ ACCELERATE SW SIG GND THROTTLE ACTUATOR CTRL CLOSE THROTTLE ACTUATOR CTRL OPEN THROTTLE ACTUATOR CTRL OPEN THROTTLE ACTUATOR CTRL CLOSE THROTTLE POS SENS LOW REF THROTTLE POS SENS SIG UNDERHOOD FUSE BLOCK UP/DOWN SW SIG W/ ADAPTIVE CRUISE W/O ADAPTIVE CRUISE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/WHT WIRE
