Buick Enclave II (2017-2021) sport switch Wiring diagram
This page shows the only wiring diagram for the component.sport switch, which is found in the car Buick Enclave II (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sport switch (1 of 1)
BATT POS VOLT
BATTERY POSITIVE VOLT
BCM 1 FUSE
BLK WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (FRONT OF CENTER CONSOLE)
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DC DC TRANS 1 FUSE
DRIVER INFORMATION CENTER DISPLAY
DRIVER MODE 1 IND CTRL
GMLAN SER DATA (-) (2)
GMLAN SER DATA - (1)
GRN/GRY WIRE
GRN/PPL WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
LEFT FRONT SHOCK ABSORBER ACTUATOR
LEFT FRONT VERTICAL SUSPENSION ACCELERATION SENSOR
LEFT REAR SHOCK ABSORBER ACTUATOR
LF DAMP SERVO CTRL
LF WHEEL DAMP ACCEL SIG
LF WHEEL DAMPING ACCELEROMETER LOW REF
LOGIC
LOW SPD GMLAN SERIAL DATA 2
LR DAMP SERVO CTRL
NCA WIRE
POWER DISTRIBUTION SYSTEM
POWER SUPPLY TRANSFORMER
REAR BODY FUSE BLOCK
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RF DAMP SERVO CTRL
RF WHEEL ACCEL LOW REF
RF WHEEL DAMP ACCEL SIG
RIGHT FRONT SHOCK ABSORBER ACTUATOR
RIGHT FRONT VERTICAL SUSPENSION ACCELERATION SENSOR
RIGHT REAR SHOCK ABSORBER ACTUATOR
RR DAMP SERVO CTRL
SADS FUSE
SERIAL DATA COMM ENABLE
SHIFT SELECT SW PERFORMANCE SIG
SPLY VOLT 1
SPORT IND
SPORT SWITCH
SUSPENSION CONTROL MODULE
UNDERHOOD FUSE BLOCK
VEHICLE STABILITY CONTROL SWITCH
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL/RED WIRE
Go to component -> Electronic suspension circuit -> SPORT SWITCH
