Buick Enclave II (2017-2021) fold seats sw fuse Wiring diagram
This page shows the only wiring diagram for the component.fold seats sw fuse, which is found in the car Buick Enclave II (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fold seats sw fuse (1 of 1)
BATTERY FUSE BLOCK
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
FOLD SEATS SW FUSE
FUSE 5
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
LH FORWARD LOCK ACTUATOR CTRL
LH MOTOR FORWARD CTRL
LH MOTOR REARWARD CTRL
LH POSITION SENS SIG
LH REARWARD LOCK ACTUATOR CTRL
LH RECLINE FORWARD SIG
LH RECLINE REARWARD SIG
ORG/ WIRE
OUT OF
PARK SIG
PPL
PPL/BLK WIRE
PPL/GRY WIRE
PPL/RED WIRE
REAR BODY FUSE BLOCK
RED WIRE
RED/BLU WIRE
RH FORWARD LOCK ACTUATOR CTRL
RH MOTOR FORWARD CTRL
RH POSITION SENS SIG
RH REARWARD CTRL
RH REARWARD LOCK ACTUATOR CTRL
RH RECLINE FORWARD SIG
RH RECLINE REARWARD SIG
SEAT RECL FUSE
SEAT SENS VOLT REF 1
SEAT SENS VOLT REF 2
TRANSMISSION PARK POSITION RELAY
WHT WIRE
WHT/PPL WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/WHT WIRE
Go to component -> 3rd row folding seat circuit -> FOLD SEATS SW FUSE
