Buick Enclave II (2017-2021) drv door open sw sig Wiring diagram
This page shows the only wiring diagram for the component.drv door open sw sig, which is found in the car Buick Enclave II (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drv door open sw sig (1 of 1)
BATT POSITIVE VOLT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/PPL WIRE
BODY CONTROL MODULE (FRONT OF CENTER CONSOLE)
COMPUTER DATA LINES SYSTEM
DRIVER DOOR LATCH ASSEMBLY
DRV DOOR OPEN SW SIG
ESCL FUSE
GRN WIRE
GRN/PPL WIRE
HI SPEED GMLAN SERIAL DATA (-) 1
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
INSTRUMENT PANEL FUSE BLOCK
KEYLESS ENTRY CONTROL MODULE
LO SPD GMLAN SER DATA
LO SPD GMLAN SERIAL DATA
LOGIC
OFF/ACCESSORY VOLT
RED/GRY WIRE
SIG GND
STEERING COLUMN LOCK MODULE (TOP SIDE OF STEERING COLUMN)
STEERING COLUMN LOCK STATUS SIG
STR COL LCK STATUS SIG
STR COL LOCK SIG
UNDERHOOD FUSE BLOCK
WHT WIRE
WHT/YEL WIRE
Go to component -> Steering lock circuit -> DRV DOOR OPEN SW SIG
