Buick Enclave I (2007-2013) w/o express (in power passenger door harness, windows Wiring diagram
This page shows the only wiring diagram for the component.w/o express (in power passenger door harness, windows, which is found in the car Buick Enclave I (2007-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o express (in power passenger door harness, windows (1 of 1)
BLK WIRE
DATA LINK CONNECTOR (DLC)
DIGITAL HAZARD DIGITAL VIDEO SWITCH VIDEO DISC (DVD) CONTROL DISC MODULE RELAY
DK BLU WIRE
DRIVER DOOR DOOR DOOR LOCK UNLATCH UNLOCK PUMP RELAY RELAY RELAY RELAY
DRIVER DOOR LATCH
DRIVER DOOR LOCK SWITCH
DRIVER DOOR LOCK/ WINDOW SWITCH
DRIVER OUTSIDE REARVIEW MIRROR
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT LUMBAR SWITCH
DRIVER WINDOW MOTOR
DRIVER WINDOW SWITCH
LEFT I/P COURTESY LAMP
LEFT REAR DOOR LATCH
LEFT REAR WINDOW SWITCH
NCA WIRE
PASSENGER DOOR LATCH
PASSENGER DOOR LOCK SWITCH
PASSENGER DOOR LOCK/ WINDOW SWITCH
PASSENGER OUTSIDE REARVIEW MIRROR
PASSENGER WINDOW SWITCH
REAR WINDOW WASHER
RIGHT I/P COURTESY LAMP
W/ EXPRESS POWER WINDOWS
W/ FRONT HEATED SEAT
W/ MANUAL FOLDING
W/ POWER FOLDING
W/ SPO DVD
W/ TRAILER PROVISIONS
W/ W/ POWER MANUAL FOLDING FOLDING
W/O EXPRESS (IN POWER PASSENGER DOOR HARNESS, WINDOWS
W/O EXPRESS POWER WINDOWS
W/O FRONT HEATED SEAT
W/O MEMORY, 8-WAY DRIVER POWER SEAT
Go to component -> Ground distribution circuit (3 of 5) -> W/O EXPRESS (IN POWER PASSENGER DOOR HARNESS, WINDOWS
