Buick Enclave I (2007-2013) w/ multi- directional passenger seat adjuster Wiring diagram
This page shows the only wiring diagram for the component.w/ multi- directional passenger seat adjuster, which is found in the car Buick Enclave I (2007-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ multi- directional passenger seat adjuster (1 of 1)
BLK WIRE
DK BLU WIRE
DK GRN WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK (BEHIND RIGHT END OF DASH)
LT GRN WIRE
PASSENGER SEAT ADJUSTER SWITCH
PASSENGER SEAT HORIZONTAL MOTOR (UNDER FRONT PASSENGER'S SEAT)
PASSENGER SEAT RECLINE MOTOR (IN FRONT PASSENGER'S SEAT BACK)
PASSENGER'S LUMBAR CIRCUIT
RED WIRE
RED/WHT WIRE
RT/PWR/SEAT CIRCUIT BREAKER
RWD
TAN WIRE
W/ 4-WAY PASSENGER SEAT ADJUSTER
W/ MULTI- DIRECTIONAL PASSENGER SEAT ADJUSTER
WHT WIRE
Go to component -> Passenger power seat circuit -> W/ MULTI- DIRECTIONAL PASSENGER SEAT ADJUSTER
